GYS AUTO P3
A 220 A single-phase pulse inverter with three built-in wire feeders, so steel, aluminum and silicon bronze are each loaded, gassed and ready — no spool swaps between jobs. Synergic setup, collision programs and 200 job memories keep every technician on the same weld.
Three materials loaded. Zero spool swaps.
Each of the P3's three 4-roller feeders is dedicated to one wire — steel, aluminum, silicon bronze — with its own 118-inch torch. Pick the job on the screen and the machine is welding the right material in seconds, with the correct synergy, without anyone touching a spool or a liner. On a busy collision floor that is the difference between finishing the panel and waiting on the welder.
Three 4-roller drives
Independent drives with digital encoders for smooth, consistent feed on long runs and thin gauge.
One per material
Steel Ø 0.6 / 0.8 mm, aluminum Ø 1.0 / 1.2 mm and CuSi Ø 1.0 mm — all 118".
Two cylinders aboard
Room for two 20 L (4 m³) cylinders, so the shielding gas changes over with the material. Reinforced wheels roll the whole setup between bays.
Three processes. One correct weld.
Choose the material and thickness on the 3.5" color screen and the P3 builds the synergy — current, voltage, wire speed and pulse. Save it as one of 200 jobs and every technician runs the same weld tomorrow.
Standard MIG/MAG
Synergic short-arc for steel and stainless outers, rails and reinforcements.
Pulse
Controlled heat input for aluminum and silicon bronze — clean beads, no burn-through.
Manual
Full control of every parameter for the specialist and the odd job.
2T / 4T
Trigger modes for short tacks or long seams without holding the trigger.
The spec sheet, in full.
Ref. 080928 as it ships: the inverter and its three feeders on the reinforced cart, the torch support arm, three 118" torches and the 137" earth clamp.
Welding performance
- Welding current range
- 10 – 220 A
- Processes
- MIG/MAG — Standard · Pulse · Manual
- Trigger modes
- 2T and 4T
- Materials
- Steel, stainless steel, aluminum, CuSi, CuAl
- Wire diameters
- Steel 0.6 – 1.2 mm · aluminum 0.8 – 1.2 mm · CuSi / CuAl 0.8 and 1.0 mm
- Pulse function
- Yes — aluminum, CuSi and more
- Arc control
- Digital arc, low spatter, fast ignition
Feeders & torches
- Built-in wire feeders
- 3 — dedicated to steel, aluminum and CuSi
- Wire feed system
- 4-roller drive with digital encoder
- Torches included
- Steel 118" (Ø 0.6 + 0.8 mm) · aluminum 118" (Ø 1.0 + 1.2 mm) · CuSi 118" (Ø 1.0 mm)
- Earth clamp
- 137", fixed
- Gas support
- Holds up to 2 × 20 L (4 m³) cylinders
Control & power
- Display
- 3.5" multilingual color interface
- Job memory
- Up to 200 custom welding programs
- Updates
- USB port for software and synergy updates
- Input voltage
- 208 – 240 V, single-phase
- PFC technology
- Yes — operates from 185 V to 265 V
- Cooling
- On-demand ventilation
Physical
- Dimensions
- 33" × 24" × 36"
- Weight
- 136 lb
- Protection class
- IP23S
- Compliance
- EN 60974-1
Built for the materials the OEMs are shipping.
A feeder of its own
Pulse MIG with a dedicated 1.0 / 1.2 mm feeder and torch for aluminum panel and structural repair to the carmakers' procedures.
0.6 to 1.2 mm
Synergic short-arc and pulse on automotive-grade and high-strength steel.
Panel bonding
Silicon-bronze and aluminum-bronze brazing for panel bonding and low-heat joints on coated steels.
Collision synergies
Collision programs out of the box and USB-updatable. Current approvals are in the OEM approvals registry.
Single-phase, sorted.
The P3 runs on 208–240 V single-phase, and its PFC front end holds a steady arc anywhere from 185 to 265 V — so it goes to work on the circuit most body shops already have, with no phase converter.
Confirm the circuit
Not sure what is on your panel? Send your dealer a photo and they will confirm the circuit with you before delivery.
The official paperwork.
GYS AUTO P3 spec sheet
The GYS technical datasheet for ref. 080928 — processes, synergies and the full spec table.
Which carmakers, which machines
The approvals registry lists which GYS machines carry which manufacturer approvals, and at what tier.
Torches, wire and gas
Which wire, which gas and which consumables for each of the three feeders. Your dealer specs it with the machine.
Specced with you, installed, and supported after.
Your GYS dealer specs the P3, the torches and the consumables with you, handles delivery and install, and trains your technicians. No dealer near you yet? We'll still take care of you.
